10.1 Information signs
10.2 Warning signs
10.3 Further warnings and operating instructions
No.
Pictogram Meaning
A
- Lifting point
Lifting the machine is only permitted at these
lifting points!
B
- Lashing point
Lashing the machine is only permitted at these points!
No.
Pictogram Meaning
C
- Warning - hot surface - risk of burning!
Hot surfaces can cause severe injuries!
Keep your hands a safe distance away
from the danger area! Use protective
clothing or protective equipment!
No.
Pictogram Meaning
D
- Attention - danger zone!
Entering the danger zone between the
feeder and the paver finisher can trigger
undesired vehicle movements; these may
lead to severe to fatal injuries!
Never enter the danger zone!
