F 54 14

Change extraction filter (o)

The air outlet shaft (A) has to be disman-

tled first in order to reach the filters.

- Open engine hood, remove screws

(B) underneath the shaft.

- Loosen clips (C) on inside of frame

and remove air outlet shaft (A).

- After completing the maintenance

work, fit the air outlet shaft again in re-

verse order.
