D 21 15
Menu Paving area /
automatic steering unit
Menu for retrieving and reset-
ting the current paving area,
for showing the steering mon-
itoring and resetting the
steering monitoring refer-
ence.
- (1) Current paving distance
- Reset - set value to zero:
button (C).
- (2) Steering monitoring is
used for distance control
scanning --> reference.
- Set reference value to zero: button (E).
A
Ideal distance scanning --> reference is the value "0" in display (2). Excursions indi-
cate increased or reduced distances.
A
If necessary, carry out correction via slight steering movement!
A
If the driver carries out a steering movement, this overrides the automatic steering
unit due to safety reasons.
2
1
E
C
