Description of assemblies and functions
Item Designation
1
t
Swivelling front flap
2
t
Swivelling side flaps
3
t
Maintenance door
4
t
Reflector plate for feeder clearance sensor
5
t
Reflector plate extension pipe - for operation on the side
6
t
Fixture for paver option "extraction system"
7
t
Tie-down rings
8
t
Lashing points for loading by crane
4
5
2
2
1
6
3
7
8
7
7
7
