B 16
5.11 Hydraulic system
5.12 Material compartment (hopper)
5.13 Material transfer
5.14 Material distribution
Pressure generation
Hydraulic pumps via distribution gear
(directly flanged to the engine)
Pressure distribution
Hydraulic circuits for:
- Travel drive
- Auger
- Conveyor
- Tamper / vibration
- Operating functions
-Fan
-Clutch
- Separate hydraulic circuits for options
Hydraulic oil reservoir - volume (See chapter F)
Volume
Approx. 6.5 m
3
= approx. 15.0 t
Minimum inlet height, centre 555 mm
Minimum inlet height, outside 560 mm
Hopper width, outside, open 3610
Type Dual conveyor belt
Width 2 x 655 mm
Conveyors Left and right auger separately controllable
Drive Hydrostatic, continuously controllable
Conveying volume controller Fully automatic via configurable switching points
Auger diameter 380 mm
Drive
Hydrostatic central drive, continuously controlla-
ble independently of the conveyor
Auger halves can be switched to opposite direc-
tions
Reversible direction of rotation
Conveying volume controller Fully automatic via configurable switching points
Auger height adjustment - Mechanically
Auger extension With extension parts (see auger extension chart)
