Dynapac SD2500C - Page 113

D 11 27
Item Designation Brief description
50
Left conveyor
"MANUAL" /
reverse
conveyor (o)
Button with detent switch function and LED feedback:
- The conveying function of the left conveyor is
switched on continuously with full delivery capacity,
without material control via the limit switches in the
material tunnel.
- Switch OFF by pressing the button again.
- Reverse conveyor: Keep button pressed for approx.
1 second. The main function switch (66) must be
switched to "OFF" in this case.
A
To avoid excessive conveying, the system is shut off at
a defined material height!
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, note danger zones of moving parts of the
vehicle!
51
Right conveyor
"MANUAL" /
reverse
conveyor (o)
Button with detent switch function and LED feedback:
- The conveying function of the right conveyor is
switched on continuously with full delivery capacity,
without material control via the limit switches in the
material tunnel.
- Switch OFF by pressing the button again.
- Reverse conveyor: Keep button pressed for approx.
1 second. The main function switch (66) must be
switched to "OFF" in this case.
A
To avoid excessive conveying, the system is shut off at
a defined material height!
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, note danger zones of moving parts of the
vehicle!
