D 11 33
Item Designation Brief description
56 Adjustment
Levelling cylinder
Button with detent switch function and LED feedback:
- For manual actuation of the levelling cylinders when
the automatic levelling system is switched off.
- Switch OFF by pressing the button again
A
The corresponding switch on the remote control must
be switched to "Manual" for this function.
A
Levelling cylinder adjustment is carried out with the ad-
justment buttons in the displayed arrow direction.
A
This function is also activated when the remote control
is not connected!
57
Auger
Lift/lower (o)
Button with detent switch function and LED feedback:
- For hydraulic adjustment of the auger height.
- Switch OFF by pressing the button again.
A
The height can be read on the scales to the left and the
right of the auger crossbeam support.
Rule of thumb: Paving thickness plus 5 cm (2 inches)
equals the auger crossbeam height.
A
Actuate both relevant adjustment switches at the same
time as the auger crossbeam otherwise jams!
A
Auger adjustment is carried out with the adjustment but-
tons in the displayed arrow direction!
