D 11 45
Item Designation Brief description
72
Travel drive
fast (hare)
Buttons with detent switch function and LED feedback:
- To preselect the speed level -
transport speed
A
On restarting, the speed is set to operating speed
(tortoise).
73
Travel drive
slow (tortoise)
Buttons with detent switch function and LED feedback:
- To preselect the speed level -
operating speed.
A
On restarting, the buttons are set to operating speed
(tortoise).
74
Straight-ahead
travel
Button with detent switch function and LED feedback:
- Normal position for straight-ahead travel.
A
On restarting, the "Straight-ahead travel" button is set.
A
If the "Turning on the spot" function has been inadvert-
ently activated (and the steering is set to straight-ahead
travel), the paver finisher does not move. This is often
interpreted as a "malfunction".
75 Turning on the spot
Button with detent switch function and LED feedback:
- The vehicle turns on the spot (the caterpillar chains
run in opposite directions) when the steering is set
to "10".
- Steering turned to the left = vehicle turns to the left
- Steering turned to the right = vehicle turns to the right
A
The function can only be activated in the "travel drive
slow" speed.
A
If the "Turning on the spot" function has been inadvert-
ently activated (and the steering is set to straight-ahead
travel), the paver finisher does not move. This is often
interpreted as a "malfunction".
f
When the vehicle turns, persons and objects next to the
paver finisher are in extreme danger. Monitor the area
where the paver finisher turns!
