Dynapac SD2500C - Page 51

B 25
No.
Pictogram Meaning
26
- Engine oil
Position of the filling and control point.
27
- Engine coolant
Position of the filling and control point.
28
- Hydraulic oil
Position of the filling point.
29
- Hydraulic oil level
Position of the control point.
30
- Engine oil drainage point
Position of the drainage point.
31
- Gearbox oil
Position of the filling and control point.
32
- Gear oil drainage point
Position of the drainage point.
