D 11 13
Item Designation Brief description
24
Move control plat-
form to the left
Pushbutton function with LED feedback:
- To move the control panel to the left
m
The platform lock must be released before moving the
control platform!
f
On actuation, note danger zones of moving parts of the
vehicle!
25
Move control plat-
form to the right
Pushbutton function with LED feedback:
- To move the control panel to the right
m
The platform lock must be released before moving the
control platform!
f
On actuation, note danger zones of moving parts of the
vehicle!
26
Push roller
Extend(o)
Pushbutton function with LED feedback:
- To hydraulically extend the push roller
crossbar.
f
On actuation, note danger zones of moving parts of the
vehicle!
27
Push roller
Retract (o)
Pushbutton function with LED feedback:
- To hydraulically retract the push roller
crossbar.
f
On actuation, note danger zones of moving parts of the
vehicle!
26
+
27
Push roller
damping
ON / OFF (o)
Detent switch function and LED feedback:
- Press both buttons simultaneously to activate push
roller damping.
- Switch OFF by pressing one of the two buttons.
A
Push roller damping hydraulically absorbs the shocks
between the material truck and paver finisher.
