16. Pilot Data
16-8
16.5 Creating New Pilot Data
You can create and modify pilot data, and this can be done in the planning mode. It is recommended to use the true
motion display mode while editing.
3.1.
2.
[Pilot Data]
Go Monitor mode
Select
Unselect
Create
Backup and Restore
Report
Close
To create a new pilot data, do the following:
1. Place the cursor on PilotData in the status bar then click the Plan button to show the Plan Pilot Data dialog box.
If you have not already chosen pilot data, the Plan Pilot Data menu also appears. If the menu is not displayed,
click the triangle mark again. Choose Create from the menu then push the scrollwheel.
2. In the pilot name entry box, spin the scrollwheel to choose character, then push the scrollwheel. Repeat to enter
name desired then click the OK button.
3. In the Edit Record page of the Plan Pilot Data dialog box, check "Enable changes". Roll the trackball to put the
cursor on the location desired for pilot data then push the left mouse button. In the Range box, enter the range
from your ship at which to activate the pilot data. To show text message on the screen, enter desired message in
the text window; spin the scrollwheel to choose character and push the scrollwheel to confirm.
16.5.1 Adding new pilot data record
To add a new pilot data record the following choices are available:
• Using the left mouse button.
• Using the Add button in the Edit page.
To add a new pilot data record by using the left mouse button:
1. Open the Edit page of the Plan Pilot Data dialog box and check Enable changes.
2. Place the cursor on the location in the chart area where you want to add a new pilot data, then push the left
mouse button. New pilot data record appears at the end of file.
3. Modify Range, Position, text message, etc. as appropriate.
