30. Steering With TOKYO KEIKI Autopilot PR-6000
30-35
30.10 How to use the Curved EBL with TOKYO KEIKI
Autopilot
The curved EBL is a control tool to monitor automatic operation of GotoOS and Goto AW (="RC/Nav") steering
modes. The curved EBL is available on ECDIS screen and on some selected radar displays.
After the WPT Approach but before start of turn, the curved EBL displays next intended turn. When your ship starts
a turn (initiated by the automatic route steering) the Curved EBL is locked to its position.
During the turn you can monitor how your ship performs the intended maneuver against the plan by comparing the
Curved EBL position and your current position.
Curved EBL at the wheel over point.
Locked curved EBL during turn.
