30.8.2 Expected steering performance for turns
Environmental
conditions
Heading control =
"AUTO"
Goto OS + "RC" Goto AW + "RC"
Calm sea, no wind,
no current
Ship performs normal
autopilot turn under
this condition.
- Ship follows monitored route. - Ship follows monitored
route.
Moderate wind
and/or current
Ship performs normal
autopilot turn under
this condition.
- Ship follows monitored route. - Ship follows monitored
route.
High wind and/or
current
Ship performs normal
autopilot turn under
this condition.
- Ship follows monitored route, but
may go outside channel limit
area.*)
- Ship may have trouble in
following monitored route inside
the channel limit.**).
- Ship follows monitored
route.*)
- Ship may have trouble in
following monitored route
inside the channel
limit.**).
Slow change of
wind and/or current
Ship performs normal
autopilot turn under
this condition.
- Ship follows monitored route - Ship follows monitored
route
Sudden change of
wind and/or current
(For example
sudden change
from no current to
5 kt current
perpendicular to
track)
Ship performs normal
autopilot turn under
this condition.
- Ship may go outside channel limit
and return back inside channel
limit.*)
- Ship may have trouble in
following monitored route inside
the channel limit.**).
- Ship may go outside
channel limit and return
back inside channel
limit.*)
- Ship may have trouble in
following monitored route
inside the channel
limit.**).
*) The track control system is able to compensate drift up to 45 degrees. If the drift is larger, your ship may go
outside the channel limit..
**) The track control system is able to compensate cross-track error up to 30 degrees. However, the full
compensation is not available immediately. Two alarms will warn the operator if the track control system estimates
that it is not able to keep your ship within channel limits. Alarm "519 Trackpilot: XTE comp. limit" informs you that
no further cross-track error based compensation is possible. Alarm "455 Route: Off course" informs you that the
track control system cannot use a higher attack angle towards the track.
