Furuno FEA-2107-BB - Appendix 9: Parts List and Parts Location; A9.1 Parts List

AP-97
Appendix 9: Parts List and
Parts Location
A9.1 Parts List
FURUNO Model FEA-2807/FEA-2107/FEA-2107-BB
Unit Processor Unit EC-1000C
Control Unit RCU-018
Control Unit RCU-015
ELECTRICAL PARTS LIST Ref.Dwg.
Blk.No.
SYMBOL PRINTED CIRCUIT BOARD/ CODE NO. REMARKS
ASSY. TYPE
CONTROL UNIT RCU-018
PNL Board 03P9343 008-544-420
BUZ Board 03P9362 008-535-600
Trackball Assy. TA4726N 000-147-139-01
CONTROL UNIT RCU-015
PNL Board 03P9344 008-536-380
Trackball Assy TA4726N 000-147-139-01
2008/09
EMC Filter FN 2080-6/06 000-165-007
DVD-ROM Drive GDR-H30N 000-160-935-10
Floppy Disc Drive FD-235HF 000-165-010
Hard Disk MHW2040 AC 000-159-044-10
SDRAM DIMM Board 77.G1136.44G 000-164-603-10
BACKPLANE Board PCI-5S-RS-R40 000-170-056-10
Power Supply UPF250-AA-BG 000-165-006-11
CPU Board Assy. PCG-820GV 001-047-000
PWR ON Board 24P0092 000-165-013
PROCESSOR UNIT EC-1000C
