Remote control set description
• As many as four servos can be controlled simulta-
neously as a block in the SAME operating mode
with a servo cycle time of 10 ms (digital servos
only).
• Thanks to cycle time reduced down to as little as
10 ms, extremely short response times are achieved.
• Real-time telemetry evaluation in the transmitter
display Additionally, telemetry data can also be
selectively displayed by the SMART-BOX.
Additional HoTT features of the
mc-32
• Super-fast response time through use of a fast
main processor for data transmission.
• Micro-SD card for storage of telemetry data and
for additional functions
• Obsolescence-proof through update capability over
USB interface as well as via the micro-SD card
• The included Lilo battery (changes reserved) has
a capacity of over 6000 mAh. This makes extreme-
ly long fl ight times possible and also reduces the
number of charging repetitions.
• Modulation changeover per software: e. g. from
"EXT. PPM" (e. g. Weatronic) to HoTT at the press
of a button.
• Swashplate limiting: This function limits the
swashplate's tilt angle to prevent the potential for
mechanical collision in helicopter 3D operation at
full-limit roll and pitch-axis
• Ring-limiter: functions similar to swashplate limi-
tation but is used for control of up to three Voith-
Schneider drives in ship models
• Channel sequencer for automating servo motion
sequences of up to three servos, e. g. to automate
the lowering of landing gear or to extend/retract
drives in self-launching gliders
• Multi-channel function for operating Graupner
product line NAUTIC modules
• Digital trimming with pseudo »analog« endless
pinions, effective per specifi c fl ight-phase
• Auto-trim function. The current stick positions
for trimming fi xed-wing or helicopter models will
be stored in trim memory at the press of a but-
ton. (Model »compensation«, activate switch and
release stick. The correction will be blended in
»gently« upon return of the stick.
• C1 changeover, brake/elec. motor: This changeover
can be implemented very easily via enhanced fl ight
phase programming. The pilot determines the stick
positions (forward/rear) at which the motor is to
switched off or the airbrakes are to be retracted.
• 16 control functions maximum
• Simplifi ed arrangement of operating elements,
such as sticks, external switches, proportional
controls and trim levers as control functions
• Protection against obsolescence is provided by
virtue of a fast 32-bit operating system with mod-
ern fl ash memory that can be updated.
• Blue back-lighted MULTI-DATA-GRAPHIK-LCD
monitor with signifi cantly better legibility under
unfavorable light conditions
• CONVENIENCE MODE SELECTOR to simplify
changeovers between operating modes 1 … 4
(e. g. throttle left/throttle right)
• Twelve freely programmable mixers for fi xed-wing
or helicopter models, each with freely selectable
input and output functions; four curve mixers with
innovative 8-point curve technology for easy to set
and adjust curve values at up to eight points for
throttle, pitch, tail or other non-linear character-
istics. The arithmetic unit in the CPU employs an
ingenious method of calculating polynomial ap-
proximations for truly-rounded, ideal MPC (multi-
point curve) mixer curves
• Shifting curve mixer points can be done along
both axes with the CAP touch pad keys
• Eight fl ight-phase programs can be individually
adapted for each model and given a name. The
As many as four servos can be controlled simulta-
Auto-trim function. The current stick positions
Computer System mc-32
32 channel remote control set in 2.4 GHz Graupner-HoTT technology
(Hopping Telemetry Transmission)
switchover time is programmable separately.
• SUPER SERVO menu with a perfect overview of
all servo setting data and simple parameter cor-
rection at four "levels": direction of rotation, mid-
point setting, separate servo travel on both sides
and separate travel limiting on both sides for 16
servos with a total of 96 setting options
• SUPER-DUAL-RATE, EXPO and EXPO/DUAL-
RATE menu with 36 potential setting variants for
three servo functions and six fl ight phases
• Practice-optimized multi-function menu for aero-
foils and helicopter models. Entry of the number
of aileron and fl ap servos automatically programs
all necessary mixer functions in the multi-function
"Wing mixers" menu. Differential aileron mixer,
butterfl y mixer, dual-fl ap mixer, automatic gyro set
function and other special functions
• Helicopter swashplate mixer for 1, 2, 3, or 4 point
steering.
• Selectable cycle time: 10 ms or 20 ms/30 ms,
depending on receiver and operating mode
• A convenient timers menu with a system of eight
stopwatches, alarm timer, countdown timer, laps
counter and so on. Two running timers and one lap
timer can be displayed at the same time in large
characters.
• Stopwatch with history: In addition to the lap coun-
ter there is a "Time 1" which captures the switch-
on time and a "Time 2" which records the ON and
OFF times separately
• Channel mapping in the receiver allows free distri-
bution of control functions.
• The travel distance and rotation direction settings
integrated into the receiver make it possible, for
example, to match up mapped servos with one
another
• The programmable fail-safe functions »Hold«,
»Off« and »Move to preset positions« that are built
