Program description - Telemetry
SETTING & DATAVIEW sensor(s)
If one or more sensors are connected to a receiver,
and this receiver is a telemetry link, you can view the
displays of any sensor subsequent to the above-de-
scribed display “RX SERVO TEST” and if necessary
change its settings.
Type transmitter mc-3 2 HoTT with firm-
ware version V1.050 or higher, recognize
automatically a sensor connected to the
receiver:
GENERAL MODULE
RECEIVER
VARIO MODULE
AIR ESC
GPS
ELECTR. AIR MODULE
There is no automatic detection of connected
sensors, these are shown here in the »Te-
lemetry« menu’s »SENSOR SELECT« sub-menu
(described below) then its settings can be manually
select or activate in addition to the previously de-
scribed receiver screens:
SENSOR SELECT
RECEIVER
GENERAL MODULE
VARIO MODULE
ELECTRIC AIR.MOD
GPS
AIR ESC
However, to actually gain access to this data, the
selected sensor/s must be connected to the receiver
system and this receiver system must have an active
telemetry connection.
If, as described in the next section, there is at least
one sensor activated which has the support of current
firmware, then it is possible to directly switch between
individual modules. However, if sensors with older
firmware are in use, it may be necessary to select
“etc.” instead of the direct sensor selection.
In either case, tap the  or  selection key of the left
touch pad…
RECEIVER
etc.
GENERAL
… then use the same keys to select up or down for
the desired module, for example:
GENERAL
RECEIVER
AIR ESC
When you again press the central SET button of the
right-hand touch pad then you confirm your choice.
If the selected module, in this case a Vario module, is
active then on the last receiver screen ("RX SERVO
TEST"), at the top right there will also be an addi-
tional "
" symbol pointing to the right. This symbol is
located just to the right of the left-pointing " " symbol
and is the visible indicator that additional display
screens can be accessed.
TELEMETRY
SETTING & DATAVIEW
SENSOR SELECT
RF STATUS VIEW
VOICE TRIGGER
TELEMETRI RCV
BIND. 1
VOLT.E
RX SERVO TEST V3.98
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 70°C
TEST : START
CH OUT TYPE:ONCE
Now use one of the  selection keys on the left or
right touch pad to switch to the selected sensor's dis-
plays and check or change its settings as described
in the manual delivered with the sensor.
