172
Program description - Wing mixers
• If you would like to alternate between the C1 stick
controlling an electric drive system and a buttery
system, then you can use the options in the
"Motor" column on the »Phase settings« menu,
refer to the example on page 300.
• You can also use the opportunity to set switch
times for a "soft" transition from ight phase to
ight phase on the »Phase settings« menu
(see page 154).
• If your model features multiple wing aps and a
"crow / buttery system" (see below), but without
additional airbrakes, then you can separate output
1 (usually freed up by the above system) from
control function input 1 (throttle/brake stick) on the
»Mix only channel« (see page 221) and use it
for another purpose with the help of a "free mixer"
(see page 218).
• If "2AIL" is set in the »Model type« menu, page
94, then ight-phase dependent ap functionality
can be achieved with appropriate offset settings for
input 5 in the »Control adjust« menu, page 108.
• For almost any menu option, you have the option
of checking your settings by switching to the
servo display screen, which is accessed with a
simultaneous tap on the selection keys of
the left touch pad.
Caution:
With aileron actuation the bars of the »Servo
display« move in the same manner and in the
opposite manner with camber changing ap
actuation.
• Note that if two ap servos have been selected,
any transmitter control assigned to input 7 will be
decoupled in the software in order to avoid errors
in operating the aps. The same applies to input
10 and the selection "2AIL 4FL".
Aileron differential
Brake settings
0%
Aileron
0%
WING MIXERS
Elevator
aileron
0%0%
–––
–––
rudder
2
3
4
5
If various flight phases are envisioned in the settings
of the »Phase settings«, page 154, and »Phase as-
signment«, page 160, menus, and these flight phas-
es have been given names, the flight phase names
will appear along the bottom display edge, e. g. «Nor-
mal».
Aileron differential
Brake settings
0%
Aileron
0%
WING MIXERS
Elevator
aileron
0%0%
–––
–––
rudder
2
3
4
5
Normal
All options can then also be programmed specific to a
flight phase.
Comments:
•
In the »Model type« menu, (page 104),
control of the brake ap mixer can be
reprogrammed from control input 1 to 7, 8
or 9 and a corresponding offset point can be set.
• Braking with raised ailerons and, if present,
lowered aps (crow system) can be implemented
by making appropriate settings on the "Crow" line
of the "Brake settings" sub-menu, page 185.
Wing mixers
Calibrating the wing flap system
Within the menu tree of the menu the sub-menus and
options available depend entirely on the number of
aileron and flap servos set up on the »Model type«
menu, page 104 …
Channel 1 curve
Switch display
Control switch
Logical switch
Phase settings
Phase assignment
Phase trim
Non-delayed chan
Timers (general)
Fl. phase timers
Wing mixers
Free mixers
… which means that the only settings listed are the
ones that can actually be configured. The resulting
menu structure gains not only in clarity but also pre-
vents potential programming errors.
For example, if “2AIL” has been preset, display of the
»Wing mixers« menu would appear (without camber
flaps)...
Tail type
Motor on C1
Normal
None
Aileron/camber flaps
2AIL
M O D E L T Y PE
Brake Offset Input 1+100%
SEL
... as shown below:
