173
Program description - Wing mixers
A range of options are available for positioning
aps. You can …
a) … simply accept one position per ight phase,
by setting only the corresponding trim values.
b) … vary the aps positioned by a) with a
transmitter control assigned to "Input 6" in
the »Control adjust« menu, page118,
and if desired by also selecting ight-phase
dependency "PH" in the "Type" column.
The selected transmitter control directly controls
the two ap servos located on receiver outputs
6 and 7 and, as required, also the two FL2
servos connected to outputs 9 and 10 assuming
that corresponding aps have been specied
on the "Aileron/camber aps" line in the
»Model type« menu. This transmitter control
indirectly controls the ap position of the ailerons
via the percentage value entered in the "AILE"
(and "AIL2") column on the "FLAP" line of the
multi-ap menu.
However, in order to improve control sensitivity
for ap settings, travel should be reduced to
about 25 % in "Input 6" line of the »Control
adjust« menu.
c) … alternatively, you can also leave the default
entry of "0 %" in the "AILE" (and "AIL2") column
on the "FLAP" line of the multi-ap menu, and
use the »Control adjust« menu to assign
both input 6 and input 5 to the same transmitter
control. You can then set the degree to which
both ap pairs are affected, optionally making
this ight phase-dependent by selecting "PH"
in the "Type" column, with the respective travel
adjustment.
Accordingly, when the respective line is selected, the
familiar switch symbol ( ) will appear on the lower
edge of the screen.
Switching delays
The delay time or switch time configured on the
»Phase settings« menu, page 142, for the respec-
tive flight phase also affects all wing mixers and thus
avoids abrupt changes to flap configurations when
switching between the flight phases.
Mixer neutral points (Offset)
For all mixers on the "Brake settings" sub-menu, the
"brake offset" to be set on the »Model type« menu is
to be configured to the transmitter control position at
which the airbrakes are retracted.
Accordingly, in the "Brake offset" line of the »Model
type« menu, see page 94, specify Input 1, 7, 8 or
9 and the offset to accommodate personal piloting
habits. When selecting "input 1", please note also that
you may need to specify your desired "Throttle min"
position "forward/back" before establishing the offset
point in the "Motor at C1" line.
Note:
If the offset is not set right at the end of the
transmitter travel, the rest of the travel is a
"dead zone", i. e. the transmitter control does
not inuence any mixers on the "Brake settings"
sub-menu. Otherwise, the mixer travel is expanded
back to 100 % automatically.
All other mixers in the »Wing mixers« menu have
their neutral point with the control at its centre, i. e.
they have no effect at this control position. The value
set is mixed in at full travel.
Basic programming procedure
1. Select the desired line with the  selection keys
of the left or right touch pad.
Depending on the line selected, the bottom line of
the display will either show the "Next page" icon
(
) or a switch icon.
2. Depending on the line selected, you will either
switch to the next page on which you carry out
the same procedure as below or the desired
value field is activated by tapping the centre SET
key of the right touch pad.
3. Use the selection keys to set the mixer ratio or
degree of differential.
To configure symmetrical mixer values, move the
transmitter control or stick to its centre position, so
that the marker frame surrounds both value fields. To
configure asymmetric values, move the transmitter
control/stick to the corresponding side.
Negative and positive parameter values are
possible, in order to be able to adjust the
respective function to the direction of servo
rotation or flap orientation.
4. A simultaneous tap on the  or  keys of the
right touch pad (CLEAR) will reset the entry value
in the given active (inverse video) field back to its
default value.
5. Complete the entry with a tap on the centre ESC
key of the left touch pad or the centre SET key of
the right touch pad.
Assigning switches
Wing mixers "Aileron 2 4 rudder" and "Flaps 6 3
elevator" can be made optionally on/off switchable by
way of a switch or expanded switch.
