GRAUPNER mc-32

262
Program description - Channel sequencer
Channel sequencer
Programming the motion sequences of up to 3 servos
Use the selection keys on the left or right touch pad
to scroll to the »Channel sequence« menu option in
the multi-function menu:
Wing mixers
Free mixers
MIX active/phase MIX-only channel
Dual mixer
Fail-safe adjust
Teacher / pupil Tx. output swap
Profi trim
Trim memory
Telemetry Channel sequence
Free mixers
MIX active/phase
MIX-only channel Dual mixer
Swashplate mixer Fail-safe adjust
Teacher / pupil Tx. output swap
Profi trim
Trim memory
Telemetry Channel sequence
Tap briefly on the centre SET key of the right touch
pad to open this menu option:
CHANNEL SEQUENCER
Channel
Channel
INACT
INACT
SET
Channel
channel
INACT
14
15
16

The »Channel sequence« menu option can be used
to execute up to 9 exactly coordinated steps for up to
three servos over a period of up to 30 seconds. Such a
sequence can be triggered by a single switch and be-
gin at an initial servo position which is freely adjustable.
For example, this makes the opening of undercarriage
doors, complete with subsequent extension of the
retractable gear, just as simple to program as opening
a wheel well with renewed closing of one undercar-
riage door once the landing gear has been lowered or
to program the raising of a cockpit canopy with subse-
quent head turns and waving performed by the pilot.
However, the prerequisite for all these actions is the
"parsing" of the desired motion sequence into practi-
cal, individual steps.
Programming procedure
On this menu option's first display page, see figure
below left, either accept the three preset channels,
14 … 16, or select an available channel, 5 … 16, for
each line to form any other desired combination, e. g.:
CHANNEL SEQUENCER
Channel
Channel
INACT
INACT
SET
Channel
channel
INACT
10
11
12

With a simultaneous tap on the  or  selection
keys of the right touch pad (CLEAR), the given chan-
nel is reset back to 5, 6 or 7.
The next step makes the control channels needed for
the channel sequence available. This is done in the
"SET" column by changing settings from "INACT" to
"ACT" and thus making the individual channels "avail-
able" to the program for sequencing. Conversely, this
also means that channels defined as "active" in the
»Channel sequence« menu are not available for
other purposes.
“Sensors”
These lines only appear, according to the firmware
version, if you have already activated at least one
sensor in the “SELECT SENSOR” sub-menu of the
»Telemetry« menu; see page 258. The method of
selecting corresponding voice messages is as de-
scribed in the previous sections.
Note:
The points you select here are entirely
independent of the “VARIO” messages.
