Remote control set description
Technical data for the
mc-32 HoTT transmitter
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Transmitter power 100 mW EIRP
Control functions 16 functions, 4 of these can be
trimmed
Temperature range -10 … +55 °C
Antenna collapsible
Operating voltage 3.2 … 4.8 V
Current draw about 500 mA
Range up to about 4 000 m
Dimensions about 252 x 252 x 60 mm
Weight about 1,685 g with transmitter
battery
Technical data for the GR-12L HoTT receiver
No. S1012
Operating voltage 3.6 … 8.4 V*
Current draw about 70 mA
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Antenna 1 x about 145 mm long,
about 115 mm of this
length encapsulated and
about 30 mm active
Plug-in servos 6
Plug-in sensors 1 (port 5T)
Temperature range about -10 … +55 °C
Dimensions about 36 x 21 x 10 mm
Weight about 7 g
Accessories
No.
Description
72.40 Transmitter straps, deluxe
Teacher/pupil cable for
mc-32 HoTT
see page 213
Replacement parts
No.
Description
71.26 Transmitter straps, Graupner HoTT
3080 Aluminum transmitter case, HoTT,
400x300x150 mm
33000.1 Transmitter battery, fl at LiIo, single cell six-
pack/6000 3.7 V TX
33002.1
Micro-SD card, 2 GB for HoTT transmitter
33032.2 Transmitter metal hanger for mc-3 2
33032.3 Hand rests for mc-32 (2 pieces)
33801 HoTT transmitter antenna
Technical data for the GR-32 Dual HoTT receiver
No. 33516
Operating voltage 3.6 … 8.4 V*
Current draw about 140 mA
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Antenna 2 x 2 diversity antennas,
about 145 mm long, about
115 mm of this length
encapsulated and about
30 mm active
Plug-in servos 16
Plug-in sensors up to four sensors
Temperature range about -10 … +55 °C
Range up to about 5 000 m
Dimensions about 63 x 30 x 14 mm
Antenna length 4 x wire 145 mm (active
antennae 30 mm)
Weight about 24 g
*
The speci cation for permissible operating voltage range
applies only to the receiver. Please note in this context
that receiver input voltage is applied without regulation to
connected servos but the voltage range for most connectible
servos (speed controls, gyros, etc.) is only 4.8 to 6 V.
The set, No. 33032, includes
• Microcomputer transmitter
mc-32 HoTT with
built-in LiIo single cell six-pack/6000 mAh/3.7 V
transmitter battery (change reserved)
• Graupner HoTT 2,4 GHz FHSS module
• integrated Bluetooth ® v2.1+ EDR module
• Electric outlet charger (4.2 V, 500 mA)
• Graupner bidirectional receiver, GR-12L HoTT
(No. S1012) for connection of up to 6 servos and
GR-32 Dual HoTT (No. 33516) for connection of
up to 16 servos
• USB adapter/interface (No. 7186.6) including
suitable USB cable for connection to a PC and an
adapter cable for receiver updates
• Micro-SD card with an adapter for a card reader
• Sturdy aluminum transmitter case with foam cush-
ioning (No. 3080)
• Graupner HoTT transmitter strap
Other accessories in Internet at www.graupner.de.
Contact or visit your local dealer. He will be glad to
provide advice.
