Transmitter description - Secret mode
Firmware Download
Prozess Start
Please Wait....
Boot Download
Success!!!
Please Wait....
…, the message:
Firmware
Downloading...
Progress 023/275
… will appear in the display. As soon as the coun-
ter to the left of the "/" character reaches the value
shown on the right as the volume to be loaded, the
message …
Firmware Upgrade
Success!!!
… will appear. After a few seconds this message will
be erased and the transmitter will automatically re-
start. The transmitter is now again operational.
Notes:
•
If the warning …
RF
MUST BE
OFF
OK
..., Then the RF section of the transmitter is still
active. Turn this in the line “RF module” of the
menu “Model basic adjustment” or turn off
the transmitter, as mentioned in this section, with
disconnected HF, and then try again.
• If the warning ...
SD-CARD
INSERT
OK
… appears then the transmitter does not detect
a memory card in its card slot or the card found
cannot be read.
• If the selection window is empty …
FILE LIST
… then the transmitter could not nd a suitable
rmware le on the inserted memory card. Check
the contents of the SD card's "Firmware" directory
on a PC or laptop.
STICK CALIBRATION
If you feel the neutral position of your self-centreing
sticks (controls 1 … 4) are not exactly 0 % of their
control travel, then this can be checked and, if neces-
sary, corrected as follows.
Jump to the »Model select« menu and initialize a
free model memory as described on page 69. Wheth-
er the model to be initialized is a winged aircraft or a
helicopter is irrelevant.
Wait for the notices which typically appear in the
transmitter's base screen following a model change
then jump to the »Servo display« menu, for example
by simultaneously touching the keys of the left
touch pad (WITHOUT any interim changes to trim
settings or other program settings).
If all four of your transmitter's stick functions are still
self-neutralizing, this display should ideally look like
the one shown below.
1
3
5
7
9
11
13
15
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
2
4
6
8
10
12
14
16
Otherwise the graph bars show current setting per-
centages for stick control functions which are not
self-neutralizing – typically for the "C1" throttle/brake
or throttle/pitch stick. For example, if the throttle/brake
stick is in its "quarter-throttle" position, the display
would appear as shown below.
