GRAUPNER mc-32

73
Program description - Model select
Model select
Call up model 1 … 80
The basic operation of the transmitters keys was
explained on pages 30 and 31 and, on the previous
double-page, explanations were provided for navigat-
ing to the multifunction list and about how to make
allocations for a new model memory. At this point we
now wish to begin with the "normal" description of
individual menu items in the sequence they are ar-
ranged in the transmitter. Therefore we will begin with
the menu …
Model select
Servo adjustment
Stick mode
Control adjust
Dual Rate / Expo
Channel 1 curve
Switch display
Model select
Copy / Erase
Suppress codes
Suppress models
Base setup model
Model type
Model select
Servo adjustment
Stick mode
Control adjust
Dual Rate / Expo
Channel 1 curve
Switch display
Copy / Erase
Suppress codes
Suppress models
Base setup model
Model type
Select the »Model select« menu with the selection
keys of the left or right touch pad then briefl y tap on
the SET key of the right touch pad.
Note:
• Firmware V109x to uncluded V1100
Attention!
Switch-OFF
the Receiver first!
If this message appears, there is a telemetry link to a
receiving system operational.
Turn off this.
• Firmware from V1101
If the currently active model “Global” bound, a model
change is only possible after switching off the receiv-
ing system for safety reasons:
Attention!
Switch-OFF
the Receiver first!
If the currently active model memory bound specifi -
cally, a model change is now possible without the
need to switch off the receiving system:
03
04
Ultimate
02
00:44hR12
Starlet
BELL47G
00:33hR08
00:22hR08
Test
trim needed

free


free

05
06
01
01:23hR16Graubele
1234g/080811
As many as 80 complete model settings, including
digital trim values for the trim wheel, can be stored.
Trimming is stored automatically such that a switcho-
ver from one model to another does not cause a
loss of current trim settings. To the right of the model
number, each occupied model memory line in this
display shows a pictograph of the model type as well
as the model’s name entered for the model in its
»Basic settings, model« menu, page 76 or 84. The
code, if present, for the receiver “bound” to the model
memory location will appear right in the line.
Now, with the  selection keys of the left or right
touch pad, select the desired model memory from the
list and activate it with a tap on the SET key. A tap on
the ESC key will cause a return to the previous menu
page without activating a model change.
Notes:
•
If, after a model change, the "Throttle too
high" warning appears, the throttle/pitch
stick (C1) or the throttle limiter – by default,
the right-side proportional rotary slider – is too far
in the full throttle direction.
• If a model change causes the message …
BIND. N/A
OK
… to appear then binding settings should be
checked.
• If a model change causes the message …
Fail Safe
setup
t.b.d.
… to appear then respective failsafe settings
should be checked.
• If battery voltage is too low, the model switchover
cannot be made due to reasons of safety. An
appropriate message will appear in the screen:
not possible now
voltage too low
