Program description - Control switches
SEL
0%
0%
0%
C1
C2
C3
–––
C4
CONTROL SWITCH
Lever1
free
+85%
STO
–––
–––
10
SEL
C1
C2
C3
C4
free
free
Combining two control switches
For more complex applications, however, it can prove
necessary to override this control switch with a sec-
ond control switch.
Example:
Control switch "C1" will now be assigned to control
function 3 (= control 3) instead of its previous
assignment "Lever1". The switching point is at its
centre point, i. e. at 0 %. The switch chosen in the
next-to-the-last right column is "C2" from the list of
expanded switches. This "C2" control switch will now
be allocated in its own line to the middle proportional
slider "Slide2", whose switch-point is +50 %:
SEL
+50%
0%
0%
C1
C2
C3
–––
C4
CONTROL SWITCH
Cnt. 1
Slide2
0%
STO
–––
–––
C2
SEL
C1
C2
C3
C4
free
free
The switching directions indicated in the fourth column
from the left will now show control switch "C2" as being
closed as long as stick (control 3) and/or "Slide 2" are
located on the other side of their switch-points.
This diversity of switching options certainly offers you
enough scope for specialized applications to suit any
type of model.
Application
In order to make these control switches usable, they
can be specifi ed in those menus which use switches
by calling them up via the additional “expanded
switches” selection menu:
Move desired switch
to ON position
(ext. switch: SET)
A brief tap on the centre SET key of the right four-way
button will afford access to the expanded switches:
M wünschten Schalter
to die EIN Position
(erw. Schalter: SET)
Control/Logic/fix switch
C2 C4 C5 C6
C7
C8
FX FXi L1 L2
C3C1
Now use the selection keys to pick the desired control
switch “C1 … C4”, fi xed switch “FX” or logical switch
“L1 … L8” or the respected inverted switch “C1i …
C4i”, “FXi” or “L1i … L8i”, for example, “C3”:
Moewünschten Schalter
to die EIN Position
(erw. Schalter: SET)
Control/Logic/fix switch
C8i L2i L4i
L5i
L6i
L7i L1 L2
C7i L1i
L8i
L3i
A brief tap on the centre SET key of the right four-way
button will adopt the selected switch into the menu:
SET SET
12:34h
1:23h
0:00
0s
SEL
STO
–––
0s0:00
G3
G3
Model time
Batt. time
Top : Stop watch
Centr: Flight tim
Note regarding the inverted switches:
If you select an inverted switch during the
assignment process – e. g. “G3i” instead of
“G3” – the only difference is that the switching
direction is simply reversed, i. e. if a particular switch
is intended to activate a function – e. g. a mixer – when
turned on, then the same switch with the “i” suf x (=
inverted) activates this function when it is turned off.
Typical applications might be a need for one and the
same switch to turn one function on, and
simultaneously to turn a second function off, and vice
versa. These facilities, especially when used in
conjunction with logical switches (described in the
following section) can be exploited to cope with
extremely complex switching systems.
