Program description - Logical switches
M wünschten Schalter
to die EIN Position
(erw. Schalter: SET)
Control/Logic/fix switch
C2 C4 C5 C6
C7
C8
FX FXi L1 L2
C3C1
Now use the selection keys to pick the desired control
switch "C1 … C8", fi xed switch "FX" or logical switch
"L1 … L8" or the respected inverted switch "C1i …
C8i", "FXi" or "L1i … L8i", for example, "L3i":
Moewünschten Schalter
to die EIN Position
(erw. Schalter: SET)
Control/Logic/fix switch
C8i L2i L4i
L5i
L6i
L7i L1 L2
C7i L1i
L8i
L3i
A brief tap on the centre SET key of the right touch
pad will adopt the selected switch into the menu.
Model time
Batt. time
Top :
Centr:
Stop watch
Flight time
Timer
–––12:34h
1:23h
0:00
0:00
0s
0s
L3I
L3I
Alarm
Timer
Remark about inverted switches:
Selection of an inverted switch for a switch
assignment, e.g "L1i" instead of "L1", simply
speci es the opposite switch direction (state),
i. e. non-inverted usage results in a certain switch
activating a particular function when it is in its
switched-on state but inverted usage results in a
certain switch activating a particular function when it is
in its switched-off state. Such applications arise when,
for example, one and the same switch is to switch one
function on but, at the same time, it is to switch a
second function off, and vice versa. Logical switches
permit other, quite complex, switching options to be
created.
