Helicopter model stick mode
“MODE 2” (Throttle at left stick)
“MODE 3” (Throttle at right stick)
“MODE 4” (Throttle at left stick)
“MODE 1” (Throttle at right stick)
pitch axis
tail rotor
pitch axis
tail rotor
throttle
roll
roll
throttle
tail rotor
tail rotor
throttle throttle
pitch axis
pitch axis
roll
roll
pitch axis
pitch axis
roll
roll
Motor/Pitch
throttle
tail rotor
tail rotor
throttle
throttle
roll
roll
pitch axis
pitch axis
tail rotor
tail rotor
Use the selection keys of the left or right touch
pad to select the “Stick mode” line. The option field
will be framed.
H-J Sandbrunner
GENERAL BASIC SETTINGS
Owners name
Voice volume
Vario volume
7
fr
–––
7
fr –––
Pre-set stick mode
1
H-J Sandbrunner
SEL
Tap on the SET key briefly. The currently displayed
stick mode will be displayed in inverse video. Now
use the selection keys of the right touch pad to select
the variant, from 1 to 4, you most frequently use. In
the future this will be used for newly initialized model
memories in the Stick mode line of the »Basic set-
tings, model« menu (page 82 ... 93), but can be
changed on an individual basis for up to 80 model
memories.
Following a simultaneous tap on the or keys
of the right touch pad (CLEAR), the display will return
to stick mode “1”.
With another tap on the ESC or SET key, the selec-
tion field will be deactivated again to permit a change
to another line.
Pre-set modulation
Standard equipment for the
mc-32 transmitter
includes a HoTT transmitter module and, under the
right front cover – as viewed from the front – a connec-
tor socket for an external RF module, see page 27.
Additionally, a transmitter-internal iFS RF module can
be installed and connected. On a model-specific ba-
sis, the transmitter can be set to use the modulation
of any one of these three RF modules by appropri-
ately selecting "HoTT", "EXT. PPM" or "INT. PPM" in
the "Pre-set modulation" line of the »Basic settings,
model« menu (page 82 ... 93).
The most frequently used variant should logically
be selected for the "Pre-set modulation" line in the
"General Basic Settings" menu. In the future this will
be used for newly initialized model memories, but can
be changed on an individual basis for up to 80 model
memories.
Briefly tap the centre SET key of the right touch pad:
H-J Sandbrunner
GENERAL BASIC SETTINGS
Owners name
Touch-beeps vol.
7
fr
–––
Pre-set stick mode
1
H-J Sandbrunner
Pre-set modulation
HoTT
SEL
Now use the selection keys of the right touch pad to
select the variant from among "HoTT", "EXT. PPM"
and "INT. PPM".
A simultaneous tap on the or keys of the
right touch pad (CLEAR) will return the display back
to modulation "HoTT".
With a brief tap on the SET or ESC key, the selected
field is deactivated to permit a switch to another line.
Pre-set DSC Output
In the line with the same name in the »Basic set-
tings, model« menu (page 89 ... 100), a separate
specification can be made from among the four
available modulation types which is specific to each
model memory and will then provided at the DSC
socket. This choice primarily influences the maximum
number of control channels which can be attached to
the DSC (direct servo control) socket, and thus also
available to a flight simulator or teacher/pupil system.
By selecting "PPM10" this will be control channels 1
… 5, for "PPM16" channels 1 … 8, for "PPM18" chan-
nels 1 … 9 and for "PPM24" channels 1 … 12.
