Programming examples - Helicopter models
As a reminder:
The autorotation phase has absolute
precedence.
Therefore, move the autorotation switch back again
then put the selected switch, in the example the
three-stage switch connected to switch plug-in loca-
tions 6 and 7, initially to one of its limit positions. Now
use the selection keys to change to the bottom right
and activate this entry field:
P H A S E ASSIGNMENT
prior.
C
combi
A
B D E F
2 6 7
1 Normal
Now use the selection keys to select the desired flight
phase for this – for example "2 Hover" …
P H A S E ASSIGNMENT
prior.
C
combi
A
B D E F
2 6 7
2 Hover
… and confirm this selection with a brief tap on the
centre SET key of the right touch pad or go ahead
and put the switch into its other limit position and
define the name for this new switch position, such as
«3 Speed».
P H A S E ASSIGNMENT
prior.
C
combi
A
B D E F
2 6 7
3 Speed
The switch's middle position then receives the name
"1 Normal":
P H A S E ASSIGNMENT
Prior .
C
combi
A
B D E F
2 6 7
1 Normal
Note:
Exchanged or different name assignments for
the three switch positions are, of course, also
possible.
The model settings made before the assignment of
a phase switch are now in the flight phase "Normal".
This is the phase which is called after the above defi-
nition in the switch centre position.
This normal setting, which was already tested in
flight, can be copied to a different flight phase so that
flying can take place in the same manner in every
phase at first. For this purpose, use the menu …
»Copy / Erase« (page 74)
Copy flight phase
Erase model
Copy model –> model
Export to SD
Import from SD
=>
With the operation of the flight phases, it is possible
to carry out changes in the phase-dependent menu
for each individual phase. Since the
mc-32 HoTT
system has digital trimming, in addition to the flight-
phase dependent menu settings in the helicopter
program, the trim positions of roll, nick and tail rotor
stick can also be selected for storage on a flight-
phase dependent basis, see »Stick mode« menu,
page 116:
0:00h
Stop watch
Flight tim
K78
0:00.0
4.1V
0:00.0
00
0
0
0:00h
M
V
H-J Sandbrunner
Normal
#02
Starlet
RX VOLT:4.9V
Enhancement recommendation: Rotational speed
regulator
At some point in time you may want to install a ro-
tational speed regulator in the helicopter, such as
mc-Heli-Control, in order to be able to fly with speeds
automatically kept at a constant. In the process, it is
logical to couple the individual rotational speeds with
the flight phases so that further additional adjust-
ments are possible.
It is mandatory for the transmitter-side programming
that the rotational speed regulator was installed and
