Physical control, switch and control switch assignments
Notes:
•
Switching for some special functions may
be better implemented from a certain
freely programmable control position
rather than switching them manually with a normal
switch.
To this end, there are a total of 8 so-called "control
switches", C1 … C8, available whose switching
direction can be established, even inverted, in the
»Control switch« menu, page 146.
• Two switches and/or also control switches can be
combined with one another to form the logical "AND"
or "OR" functions via the »Logical switch« menu,
see page 150. A total of 8 logical switches "L1 … L8"
(as well as another 8 inverted logical switches with
inverted switching direction) are available.
The result of a logical switch function can also
be used as an input for another logical switch
function. Refer to the appropriate menu for more
details about this.
• The two FX switches switch a function on "FXI" or
off "FX
" permanently.
• All switches mentioned can have multiple
assignments. Pay attention that you do not
UNINTENTIONALLY assign reciprocally conicting
functions to a single switch. If necessary, note
down the given switch functions.
Typical applications:
• Shut-off of an on-board glow plug heater upon
underrun or overrun of an idle threshold point
programmed for the C1 stick. In this case the glow
plug heater switch is controlled by a transmitter
mixer.
• Automatic switch on/off of the timer to measure
pure "ight time" for a helicopter by way of a
control switch on the throttle limiter.
• Automatic switch off of the "AI  Rud" mixer when
brake aps are extended, for example to adapt
the roll of a model to the ground when making a
landing on a slope without inducing a change of
ight direction due to inuence on the rudder.
• Extending landing aps with elevator trim adjustment
during a landing as soon as the throttle stick is
moved beyond its switch point.
• Switch on/off of the timer for measuring the
operating time of electric motors.
