7-6
Total Multicast 0 1024
Table 7-3 display mac-address statistics command output description
Field Description
MAC TYPE
MAC address type:
Dynamic Unicast
Static Unicast
Total Unicast
Dynamic Multicast
Static Multicast
Total Multicast
LEARNED Dynamically learned MAC addresses
USER-DEFINED User defined MAC addresses (dynamic and static)
SYSTEM-DEFINED
MAC addresses generated by the system (for example, 802.1x and MAC
authentication)
IN-USE Number of existing MAC addresses of a specific type
AVAILABLE Maximum number of MAC addresses supported by the system
mac-address (interface view)
Syntax
mac-address { dynamic | static } mac-address vlan vlan-id
undo mac-address { dynamic | static } mac-address vlan vlan-id
View
Layer 2 Ethernet interface view, Layer 2 aggregate interface view
Default Level
2: System level
Parameters
dynamic: Dynamic MAC address entries. Aging time is set for these entries.
static: Static MAC address entries. They do not age but you can add or remove them.
mac-address: Specifies a MAC address in the format of H-H-H, where 0s at the beginning of each H
(16-bit hexadecimal digit) can be omitted; for example, inputting “f-e2-1” indicates that the MAC
address is “000f-00e2-0001”.
vlan vlan-id: Specifies an existing VLAN to which the Ethernet interface belongs, where vlan-id is the
specified VLAN ID, in the range 1 to 4094.
Description
Use the mac-address command to add or modify a MAC address entry on a specified interface.
Use the undo mac-address command to remove a MAC address entry on the interface.
