mask oui-mask: Specifies the valid length of the OUI address by a mask in the format of H-H-H,
formed by consecutive 1s and 0s, for example, FFFF-0000-0000. To filter the voice device of a specific
vendor, set the mask to FFFF-FF00-0000.
description text: Specifies a string that describes the OUI address. The string is of 1 to 30
case-sensitive characters.
oui: Specifies the OUI address to be removed, in the format of H-H-H, such as 1234-1200-0000. An
OUI address is the logic AND result of mac-address and oui-mask. An OUI address cannot be a
broadcast address, a multicast address, or an address of all 0s or all 1s. You can use the display
voice vlan oui command to display the OUI addresses supported currently.
Description
Use the voice vlan mac-address command to allow packets carrying the specified OUI address to
pass through.
Use the undo voice vlan mac-address command to disallow packets carrying the specified OUI
address to pass through.
The system supports up to 16 OUI addresses.
By default, the system is configured with the default OUI addresses, as illustrated in
Table 16-3. You
can remove the default OUI addresses and then add recognizable OUI addresses manually.
Table 16-3 Default OUI addresses
Number OUI Description
1 0001-e300-0000 Siemens phone
2 0003-6b00-0000 Cisco phone
3 0004-0d00-0000 Avaya phone
4 00d0-1e00-0000 Pingtel phone
5 0060-b900-0000 Philips/NEC phone
6 00e0-7500-0000 Polycom phone
7 00e0-bb00-0000 3com phone
Related commands: display voice vlan oui.
Examples
# Add a recognizable OUI address 1234-1200-0000 by specifying the MAC address as
1234-1234-1234 and the mask as fff-ff00-0000, and configure its description string as PhoneA.
<Sysname> system-view
[Sysname] voice vlan mac-address 1234-1234-1234 mask ffff-ff00-0000 description PhoneA
voice vlan mode auto
Syntax
voice vlan mode auto
undo voice vlan mode auto
