9-13
Aggregation Interface: Bridge-Aggregation20
Aggregation Mode: Static
Loadsharing Type: Shar
Port Status Oper-Key
--------------------------------------------------------------------------------
GE1/0/1 U 1
Table 9-6 display link-aggregation verbose command output description
Field Description
Loadsharing Type
Load sharing type:
Shar for load sharing
NonS for non-load sharing
Port Status Port state: Selected or unselected.
Flags
One-byte LACP state flags field. From the least to the most significant bit, they
are represented by A through H as follows:
A indicates whether LACP is enabled. 1 for enabled and 0 for disabled.
B indicates the timeout control value. 1 for short timeout, and 0 for long
timeout.
C indicates whether the link is considered as aggregatable by the sending
system. 1 for true, and 0 for false.
D indicates whether the link is considered as synchronized by the sending
system. 1 for true, and 0 for false.
E indicates whether the sending system considers that collection of incoming
frames is enabled on the link. 1 for true and 0 for false.
F indicates whether the sending system considers that distribution of
outgoing frames is enabled on the link. 1 for true and 0 for false.
G indicates whether the receive state machine of the sending system is using
default operational partner information. 1 for true and 0 for false.
H indicates whether the receive state machine of the sending system is in the
expired state. 1 for true and 0 for false.
If a flag bit is set to 1, the corresponding English letter that otherwise is not
output is displayed.
Aggregation Interface Name of the aggregate interface
Aggregation Mode
Mode of the aggregation group: Static for static aggregation, and Dynamic for
dynamic aggregation.
System ID
Local system ID, which comprises the system LACP priority and the system
MAC address.
Local Information about the local end
Port Port type and number
