5.2.2.1 ProView 7000 Decoding Configuration
To access the Decoding Configuration menu:
❖ Navigate Root > 2 Decoding > 1 Configuration.
The Decoding Configuration menu provides the following options:
■ Service Selection Mode – (for details see 5.2.2.3 Service Selection Mode Menu)
■ Input Selection – Select the transport stream (1–4).
■ Programs – displays a list of the programs available at the multiplexed input and select the
program to be decoded. The screen provides the program name (if the input stream
provides the SDT table), program identification (decimal number of the program number),
the program type (TV or Radio) and the program mode (CAS/scrambled or FTA/free).
Selecting a program, deselect the previous one (radio buttons selection).
■ Descrambling – selects the descrambling device for the modulated program.
Options CAM 1, CAM 2 or None (radio buttons selection).
■ Video – sets-up the video modulation parameters, depending on the video codecs and
format (for details, see 5.2.2.4 Video Configuration Menu).
■ PCR – selects the clock source for the decoded program and sets-up the a/v sync
parameters (for details, see 5.2.2.5 PCR Configuration Menu).
■ Audio1/2 – sets-up the audio decoding parameters for each one of the two audio channels
in the program (for details, see 5.2.2.6 Audio 1 / 2 Configuration Menu).
■ VBI – sets-up the VBI/VANC parameters for the various program related functions (for
details, see 5.2.2.7 VBI Configuration Menu).
TIP: The ProView 7000 decoding management is equally performed using the EMS.
Refer to 4.5.4.7 Decoding Channel Properties for details.
Configuration
Service Selection Mode
Program selection
Input Selection
Programs
Descrambling
Video
PCR
Audio1
Audio2
VBI
