Chapter 4: Router Connections
8. On the MKE-3901 back module, connect the Key 2 input source to Key 2
and Fill 2 as appropriate.
9. On the MKE-3901 back module, supply Squeeze Bkgd by an external
router.
10. Connect the two Ethernet ports as follows:
Ethernet 1 (connection for MKE-3901 control) to a switch using a
straight-through Ethernet cable
Ethernet 2 (two connection options for MGI-3903 control and logo
download)
• To the same switch as Ethernet 1 using a normal Ethernet cable
• To a dedicated switch used for the MGI functionality using a normal
Ethernet cable
11. Power up the system.
4. Set the IP Address for the MKE-3901 Module
1. Press the left (Esc) button until the message MKE3901 appears on the VFD
display.
2. Press the right (Enter) button.
3. Use the toggle switch (Nav) to scroll through the parameter list until Status
is highlighted.
4. Press the right (Enter) button.
5. Use the toggle switch (Nav) to scroll through the parameter list until Other
is highlighted.
6. Press the right (Enter) button.
7. Use the toggle switch (Nav) to scroll through the parameter list until
IP_Address is highlighted.
8. Press the right (Enter) button.
9. Continue pressing the right (Enter) button until the cursor is under the digit
you want to change.
10. Use the toggle switch (Nav) to change the digit.
11. Press the right (Enter) button to move to the next digit.
12. Repeat the previous three steps until you have changed the IP address.
13. Press the right (Enter) button until the cursor is under the space at the end
of the IP address.
14. Press the left (Esc) button to accept the change.
Note
If you are connecting Ethernet 1 to a switch, the IconMaster
control panel must be connected to the same network.
