Chapter 11: Specifications
Inputs
Serial Digital Video
Analog Video Reference
Table 11-1. Serial Digital Video Specifications
Item Specification
Number of inputs 7; A, B, Fill1, Key1, Fill2, Key2, squeeze background
Standard
SDTV
HDTV
270 Mb/s per SMPTE 259M 525i/59.94, 625i/50
1.485 Gb/s serial per SMPTE 292M 1080i/50, 1080i/
59.94, 720p/50, 720p/59.94
Equalization Automatic up to 100m (328 ft.) of Belden 1694
Connector type BNC
Return loss >15 dB
Impedance 75Ω
Table 11-2. Analog Video Reference Input Specifications
Item Specification
Connector type BNC
Number of inputs 1 Genlock
Return loss -40 dB to 6 MHz
Impedance 75Ω
Reference type NTSC/PAL, color black, or 525/625 comp sync or
Tri-Level per SMPTE 240M
29.97/30/60/25
Level 200 mV to 2 V nominal
Connector type BNC
