116 IconMaster Installation and Configuration Manual
Chapter 4: Router Connections
System Configurations—Platinum Routers
System configurations for NEO routers start on page 77. System
configurations for Panacea routers start on page 91.
This section describes the connections that are required in some typical
configurations involving Platinum external routers. The following Platinum
router configurations are described in this section:
• IconMaster System, External Platinum Video Router, Optional
ICONM-BO-V Module
• Sample Configuration 2: IconMaster System, External Platinum Video
Router, Optional CENTRIO, Optional JLCooper eBox, Optional
ICONM-BO-V Module
