IconMaster Installation and Configuration Manual 245
Chapter 11: Specifications
Outputs
Digital Video
Keyers
System Video Delay
Table 11-3. Digital Video Outputs Specifications
Item Specification
Standard
SDTV
HDTV
270 Mb/s per SMPTE 259M 525i/59.94, 625i/50
1.485 Gb/s serial per SMPTE 292M 1080i/50, 1080i/
59.94, 720p/50, 720p/59.94
Connector type BNC
Number of outputs 4; PGM (2), PST, CLEAN
Return loss >15 db
Impedance 75Ω
Table 11-4. Keyer Output Specifications
Item Specification
Number of keyers 6 (2 for IconMaster LITE)
Number of key
processors
2 external fill+key
4 internal (0 internal for IconMaster LITE)
Key modes Multiplicative; additive; self (Key 1, 2); matte (Key 1, 2)
Table 11-5. System Video Delay Specifications
Item Specification
FX module installed +1 frame
No FX module installed
SDTV
HDTV
3.7 μs + (0 to 1) video line
1.5 μs + (0 to 1) video line
