IconMaster Installation and Configuration Manual 91
Chapter 4: Router Connections
System Configurations—Panacea Routers
System configurations for NEO routers start on page 77. System
configurations for Platinum routers start on page 116.
This section describes the connections that are required in some typical
configurations involving Panacea external routers. The following Panacea
router configurations are described in this section:
• IconMaster system with external Panacea video router and optional
ICONM-BO-V module
• IconMaster System with external Panacea video router and optional
ICONM-BO-V module with optional SPT-LSERIAL serial protocol
translator
• IconMaster system with external Panacea clean quiet video router and
optional ICONM-BO-V module with optional SPT-LSERIAL serial
protocol translator
• IconMaster system with external Panacea (single channel) audio and video
routers and optional ICONM-BO-VAC module with optional
SPT-LSERIAL serial protocol translator
• IconMaster system with external Panacea (two channel) audio and video
routers and optional ICONM-BO-VAC module with optional
SPT-LSERIAL serial protocol translator
