10 IconMaster Installation and Configuration Manual
Chapter 2: Installation
Installation Notes
• All IconMaster components must be mounted in an area where there is
unrestricted air movement. Except for the MKE, MGI, and MKA modules
(which are mounted in standard NEO frames) no fan cooling is required.
• The two control panels of the IconMaster system are designed for desk and
tabletop operation, or for use in a standard equipment rack.
• For maximum efficiency and reliability, IconMaster control panels should
be operated in an ambient temperature between 68° and 86°F (20° to 30°C)
non-condensing.
• IconMaster control panels communicate with the MKE-3901 via an
Ethernet network. On the same network, the MGI-3903 also connects to the
PC that hosts the IconMaster configuration utility software.
• If your network includes a switch, the switch must be 10Base-T or
10/100Base-T. The system will not function on 100Base-T.
• NEO frames require an ambient temperature between 32° and 122°F (0°
and 45°C.) See the technical manual of your PC for information on the
operating temperatures of the computer.
• NEO modules used in an IconMaster system must be connected together in
the following top-to-bottom order before being inserted in a NEO frame:
1. MKA-3901 (optional)
2. MKE-3901 (with optional MKE-3901-FX submodule)
3. MGI-3903
Because the modules are physically connected together, they must all be
installed on the same side of the frame.
CAUTION
If your IconMaster package was not factory-installed in
a NEO frame, ensure that you use the provided screws
to secure the modules together before they are inserted
in the frame.
