IconMaster Installation and Configuration Manual 183
Chapter 8: Configuring IconMaster
Keyer Settings
The Keyer dialog box allows you to give a name to the external keyers. These
names are displayed on the keyer LCD displays of the RCP control panel.
Figure 8-21. Keyer Dialog Box
Changing a Keyer Input Source Name
To change the Name of the input source, double-click the name in the cell, and
then enter a new name. The length of the name is limited to 10 characters
(including spaces), over 2 lines, with a maximum of 5 characters per line.
Control Group Settings
The Control group on the left side of the IconMaster configuration software
screen includes the following dialog boxes: Machine Control and GPI-GPO.
Figure 8-22. Control Menu Group
This menu group controls the machine control and GPI-GPO configuration
functions, as shown in Figure 8-22.
