IconMaster Installation and Configuration Manual 5
Chapter 1: Introduction
IconMaster Components
A complete IconMaster setup consists of main components, optional items,
NEO modules, and routers.
Main Components
Hardware Components
• A main control panel with one power supply (For redundant power supply
operation, two power supply units may be used)
• A 3RU NEO frame with redundant power supplies
• An MKE-3901 mixer/keyer module
• An MGI-390x IconLogo graphics module
Software Components
• Icon Series Soft Tools CD, which includes
• IconMaster Configuration Utility (ICU)
• Content Editor
• LogoCreator
• IconLogo Soft Panel
Optional Items
• An additional power supply (for redundant power supply operation)
• An audio control panel
• An MKE-3901-FX effects optional submodule (for MKE-3901 module)
• An MKA-3901 balanced audio module
• An ICONM-BO-V video breakout module
• A balanced (ICONM-BO-VAB) or a coaxial (ICONM-BO-VAC)
audio/video breakout module
• An internal router, such as NEO NSM routers
• An external router, such as Platinum, Integrator, or Panacea
• A general purpose interface box, such as a JLCooper Electronics eBOX™
Quad Serial to Ethernet Interface
1
1
eBOX is a trademark of JLCooper Electronics.
