Harris IconMaster - Operating Standard; System Timing; Managing ICU Databases

IconMaster Installation and Configuration Manual 153
Chapter 8: Configuring IconMaster
Operating Standard
The default operating standard for IconMaster is SD525 (270Mbit/sec). To
change the operating standard, access the Genlock and Standard (see page 191
for more information on changing this setting).
System Timing
Changing the system timing causes the IconMaster system to adjust the
horizontal and vertical phase of the reference input so that the most number of
inputs have their vertical timing value at zero. To make changes to the
IconMaster timing, access the Genlock and Standard dialog box (see
page 191) to make changes to the IconMaster timing.
Managing ICU Databases
Note
Instructions on enabling a RouterMapper database for use with an
IconMaster system begin on
page 218.
ICU uses XML databases to store configuration information about the different
IconMaster setups you develop.
You can create an ICU database from scratch or create one by opening an
existing database, renaming it, and then manipulating existing information.
Creating an ICU Configuration File
1. Start IconMaster, as explained on page 151.
2. At the IconMaster Configuration Utility main menu window, select
File → New. The New Configuration dialog box will appear.
CAUTION
Do not do a system timing activity until the IconMaster
has been downloaded with a valid configuration file with
appropriately assigned primary inputs.
Unwanted on air operation may result.
CAUTION
If you do not want your changes to appear in the active
XML database, you should create a new XML database file
before you make any changes.
