IconMaster Installation and Configuration Manual 77
Chapter 4: Router Connections
System Configurations—NEO Routers
System configurations for Panacea routers start on page 91.
System configurations for Platinum routers start on page 116.
This section describes the connections that are required in some typical
configurations involving NEO NSM internal routers. The following NEO router
configurations are described in this section:
• IconMaster System with Internal Video NSM Router and Optional
ICONM-BO-V Module
• IconMaster System with Single Channel Audio and Video NSM Routers
and Optional ICONM-BO-VAC Module
• IconMaster System with Internal (Two Channel) Audio and Video NSM
Routers and Optional ICONM-BO-VAC Module
General Information
Both Video and Audio NSMs
• Only one set of NSMs can be installed in a 3RU frame.
• The source offset for all NSM modules is 1.
• The destination offset for all NSM modules is 0.
Video-Only NSM Modules
• The first video NSM module must be assigned an X-Y level of 0.
• When ganging 2 cards together, the second module must be assigned an
X-Y level of 1.
Audio-Only NSM Modules
• The NSM-7×2AES router supports a single AES stream for both A and B
inputs on the IconMaster. If the NSM-7×2AES routers are to be used for
discrete AES audio for a full two AES (four-channel) system, four of these
router modules are required.
• The expected use would be as follows:
• NSM #1 and NSM #2 provide AES 1 for Bus A and Bus B.
• NSM #3 and NSM #4 provide AES 2 for Bus A and Bus B.
