250 IconMaster Installation and Configuration Manual
Chapter 11: Specifications
MGI-3903
Miscellaneous Items
Table 11-16. Ethernet Port Specifications
Item Specification
Standard 10/100Base-T IEEE 802.3u
Connector 8-pin RJ-45
Table 11-17. Miscellaneous Specifications
Item Specification
Timecode IN Per ANSI / SMPTE 12M, XML Female
supporting unity speed, forward counting LTC
Timecode OUT Per ANSI / SMPTE 12M, XLR Male
Ethernet 10/100BaseT IEEE 802.3u Via RJ-45, 8-pin
Temperature
probe
12-36 VDC, 4-20 mA via 44-pin, HD-type female connector
Temperature
Performance
Operating
41° – 104°F (5° – 40°C)
32° – 122°F (0° – 50°C)
