IconMaster Installation and Configuration Manual 55
Chapter 2: Installation
P8 Outputs P9 Outputs P10 Outputs P11 Outputs
1 MON 2 + CLEAN 3 + PST 4 + PST 1 +
2 MON 2 - CLEAN 3 - PST 4 - PST 1 -
3 MON 2 GND CLEAN 3 GND PST 4 GND PST 1 GND
4 MON 3 + CLEAN 4 + CLEAN 1 + PST 2 +
5 MON 3 - CLEAN 4 - CLEAN 1 - PST 2 -
6 MON 3/4 GND CLEAN 4/MON 1 GND CLEAN 1/2 GND PST 2/3 GND
7 MON 4 + MON 1 + CLEAN 2 + PST 3 +
8 MON 4 - MON 1 - CLEAN 2 - PST 3 -
P12 Inputs P13 Outputs P14 Outputs P15 Inputs
1NC PGM 1 +PGM 3 +NC
2 NC PGM 1 GND PGM 3 GND NC
3 EMER PGM 1 + PGM 1 - PGM 3 - EMER PGM 3 +
4 EMER PGM 1 - PGM 2+ PGM 4 + EMER PGM 3 -
5 EMER PGM GND PGM 2 GND PGM 4 GND EMER PGM 3 GND
6 EMER PGM 2+ PGM 2 - PGM 4 - EMER PGM 4 +
7 EMER PGM 2- NC NC EMER PGM 4 -
8 EMER PGM 2 GND NC NC EMER PGM 4 GND
Table 2-9. ICONM-BO-VAB Breakout Module Screw Terminals (Continued)
Terminal
No.
Terminal Type/Function
