IconMaster Installation and Configuration Manual 71
Chapter 3: Module Configuration
Table 3-1. MKE-3901 LED Descriptions
LED Number
LED
Name
Color Meaning (When Lit)
D1 Lock Green The module is locked to the reference
signal.
D2 AO 1 Green The Audio Over 1 function is on air.
D3 AO 2 Green The Audio Over 2 function is on air.
D4 BCG Mix Green A video background transition is in
progress.
D5 Key 1 Green Key 1 is on air.
D6 Key 2 Green Key 2 is on air.
D7 Key/MGI Green Key 3, 4, 5, or 6 is on air.
D8 FTB/FTS Green Video is black or audio is silent.
Table 3-2. MKE-3901 Module Indicator Descriptions
Module
Indicator
Color Meaning (When Lit)
Major Alarm Red (Not currently active)
Minor Alarm Yellow (Not currently active)
Power Green The module is receiving power.
Module Status Green The module is configured, loaded, and operational.
