SECTION 5
APPLICATIONS
___________________________________
This section of the manual provides setup instructions and suggested RADAR configurations settings in
various scenarios and applications. The scenarios and applications covered here are: Post Production;
Live Recording; Playback; Studio Recording; and Standalone Converters.
POST PRODUCTION
____________________________________
CONNECTING TO A 9-PIN SYNCHRONIZER
9-pin is ideal for applications requiring multiple machines to be in sync and controlled from a single
interface. RADAR locks to 9-pin commands solidly and quickly, which is why RADAR is a top choice in
Professional Post Production environments.
Connect a 9-pin cable to RADAR on the Sync Processor card labeled MACH CTRL to a synchronizer or
9-pin controller. This is the only connection required between RADAR and the 9-pin synchronizer.
To select 9-pin:
Use the , the and keys and the key to go to the MAIN MENU / SYNC
MENU / MACHINE CONTROL / SELECT TYPE dialogue and press the key.
Use the and keys to select 9-PIN and press the key.
To enable 9-pin:
Use the , the and keys and the key to go to the MAIN MENU / SYNC
MENU / MACHINE CONTROL / ENABLE dialogue and press the key.
A flashing S will appear in the Session Controller Window to show that Sony 9-pin is enabled and
waiting for commands. A solid S will appear once RADAR is receiving valid 9-pin communication.
