STANDALONE CONVERTERS
______________________________
ANALOGUE TO DIGITAL CONVERTERS
RADAR’s world class converters can be used as a front end to a DAW system. RADAR can be equipped
with AES, TDIF, ADAT, or MADI digital I/O.
For best quality use RADAR’s clock as the master clock.
To use RADAR as an Analogue to Digital converter for a DAW system, first set RADAR as the master
clock source:
Connect a clock cable from RADAR’s output into the DAW’s input.
Set the DAW to clock (sync) to external clock.
Now the DAW will be using RADAR’s internal clock for clocking.
To transfer digital audio:
Connect digital audio cables between RADAR’s outputs and the DAW’s digital inputs.
Set the DAW to input these digital inputs
Input the source into RADAR’s analogue inputs
Press the Track Arm keys on RADAR.
Enable the DAW to record.
RADAR always outputs all formats, it is not required to set the output, except for 2 ch AES
and SPDIF.
It is not required to have a drive mounted in RADAR to pass audio.
Make sure both the DAW and RADAR are set to the same sample rate.
