FILE FLATTENING
When using RADAR as a dubber, thousands of punch-ins and overdubs can be generated. By using File
Flattening each track can be quickly consolidated into one file. With RADAR’s Native BWAV recording file
format and Instant File Flattening, transfers to workstations are quick and easy.
When the recording drive is initialized for AUDIO:RADAR_BWAV, the drive can be read by any Mac or
PC computer. To access the audio on a Mac or PC first select the FLATTEN PROJECT menu item in the
FILE menu. This function consolidates all punch ins into continuous files and puts them into a user folder
that is easily accessed from a computer.
To flatten a project on a RADAR Broadcast WAV disk:
Use the , the and keys and the key to go to the MAIN MENU / FILE
MENU / FLATTEN PROJECT dialogue and press the key.
At the FILL SILENCE?: prompt the options will be:
• NO (each region will be one file)
• GAP (each track will be one file with potentially different start times)
• ALL (each track will be one file with the same start time)
Then press the key.
At the FLATTEN PROJS?: prompt the options will be:
• SELECTED PROJS (select multiple projects using key)
• CURRENT PROJ (select current project)
• ALL (select all projects)
Then press the key.
If GAP or ALL is selected and the regions contain gaps or different start times, RADAR will need
additional drive space. At the XXX MB REQUIRED PROCEED? prompt, select YES and press
the key.
The CANT CANCEL/UNDO PROCEED? prompt indicates that it is a destructive process. All
undo levels will be lost on this project. Select YES and press the key.
Use the , the and keys and the key to go to the MAIN MENU / DISK
MENU / UNMOUNT dialogue and press the key.
Remove the recording drive from RADAR and plug the drive into a receiver connected to a Mac
or PC.
The workstation computer will mount the drive and the consolidated files and project notes will be
located in a new folder titled after the project name within the USER directory.
