INPUT ROUTING
To assign a specific input to a track(s):
Use the , the and keys and the key to go to the MAIN MENU / I/O
MENU / I/O ROUTING / INPUT ROUTING and press the key.
Use the numeric keys, the and keys or the Jog/Shuttle Wheel to select the physical input
(source) number.
Use the Track Arm key(s) to select the destination track(s) and then press the key.
NOTE 1: Flashing Red on the RADARView track and meter LEDs as well as the Session
Controller TK ARM and Meterbridge EDIT indicators reveal the designated track for the
current selected input.
NOTE 2: Solid Red on the RADARView track and meter LEDs as well as the Session
Controller TK ARM and Meterbridge EDIT indicators signify that a track has a different
source input than the default 1:1.
NOTE 3: Override a previous track input routing designation simply by pressing the TK
ARM key. This will reassign the track to the current selected input.
OUTPUT ROUTING
To assign a track to a specific output:
Use the , the and keys and the key to go to the MAIN MENU / I/O
MENU / IO ROUTING / OUTPUT ROUTING and press the key.
Use the numeric keys, the and keys or the Jog/Shuttle Wheel to select the track (source)
number.
Use the Track Arm key(s) to select the destination physical output and then press the key.
NOTE 1: Flashing Red on the RADARView track and meter LEDs and on the Session
Controller TK ARM and Meterbridge EDIT indicators show the designated output for the
current selected track.
NOTE 2: Solid Red on the RADARView track and meter LEDs and on the Session
Controller TK ARM and Meterbridge EDIT indicators illustrate that an output has a
different source track than the default 1:1.
NOTE 3: Override a previous track output routing designation simply by pressing the TK
ARM key. This will reassign the output to the current selected track.
