• Record time remaining.
• Disk Mode.
• SCSI activity indicator.
• Track display for audio waveform data.
• Track naming area, inputs, outputs.
• Current digital I/O format display.
• Date and Time Display
SESSION CONTROLLER DISPLAY
The Session Controller has a 2 x 16 character display that is used to display the current timecode
position in the project, as well as all RADAR menus and dialogs. The default display shows the current
timecode location in the standard Hours:Minutes:Seconds:Frames plus sub-frames format. When menu
functions are accessed using the key or by pressing a direct access key, the display becomes
the central navigation system for RADAR. The contents of this display are mirrored on RADARView with
the exception of the default display.
INDICATORS
Metering and other indictors are provided on the RADARView display and also on the optional
Meterbridge 24 and Meterbridge 48, either of which can be connected to the Session Controller
professional remote.
METERING
Input signal is displayed on 20-segment LED meters with a scale ranging from below –55 to 0 dBFS
(decibels Full Scale), the maximum input level. A clip LED with variable hold time is also provided to help
warn of impending digital distortion. The clip LED hold time setting can be changed in the MAIN MENU /
PREFS MENU / CLIP HOLD TIME dialogue.
Use + to clear clipped meters when CLIP HOLD TIME is set to -1.
STATUS
The additional LED indicators on each channel of the Meterbridge 24 and Meterbridge 48 include:
ARM
Red-flashing LED indicators to identify tracks that are armed and ready for recording.
INPUT
Steady-state yellow LED indicators to identify tracks currently in input monitoring mode.
SOLO
Steady-state green LED indicators to identify tracks that are currently soloed.
EDIT
Red-flashing LED indicators to identify tracks that are selected for the current editing
operation.
