MACHINE CONTROL
_____________________________________
RADAR can be configured to allow external controll via Sony 9-pin or MMC (MIDI Machine Control). 9-
PIN SETTINGS and MMC SETTINGS are available to allow the RADAR to seamlessly integrate with a
wide variety of professional products that provide 9-pin and/or MMC control protocols.
9-Pin Settings:
Use the key, the and keys and the key to go to the MAIN MENU / SYNC
MENU / MACHINE CONTROL and press the key.
Use the and keys to choose SELECT TYPE and press the key.
Use the and keys to select 9-PIN and press the key.
To enable or disable 9-Pin Machine Control:
Press + (MCH CTL) on the Session Controller or use the key, the and
keys and the key to go to the MAIN MENU / SYNC MENU / MACHINE CONTROL and
press the key.
Use the the and keys till ENABLE/DISABLE is displayed.
If machine control is disabled, pressing the key will enable it. If machine control is enabled,
pressing the key will disable it.
MIDI Machine Control (MMC) Settings:
Use the key, the and keys and the key to go to the MAIN MENU / SYNC
MENU / MACHINE CONTROL and press the key.
Use the and keys to choose SELECT TYPE and press the key.
Use the and keys to select MMC and press the key.
The default MMC DEVICE ID is set to 127(7F) = ALL CALL. This does not need to be
altered unless advised by the MMC Manufacturer or iZ Support.
To enable or disable MIDI Machine Control:
Press + (MCH CTL) on the Session Controller, or use the key, the and
keys and the key to go to the MAIN MENU / SYNC MENU / MACHINE CONTROL and
press the key.
Use the and keys till ENABLE/DISABLE is displayed.
If machine control is disabled, pressing the key will enable it. If machine control is enabled,
pressing the key will disable it.
